Tool-Chek

TC200

3-7

Display resolution determines the number of decimal places the
TC200 will display. For example, if the millimeter display resolution
is set to .1, the TC200 will display a measurement of 1.2311 milli-
meters as 1.2. Any value up to the resolution of the encoder can
be entered for display resolution. Values in excess of the encoder
resolution result in accurate display information.

NOTE

NOTE
When inputting resolution remember that .0001mm is a higher

When inputting resolution remember that .0001mm is a higher

When inputting resolution remember that .0001mm is a higher
resolution than .0002mm. Therefore, any entry less than

resolution than .0002mm. Therefore, any entry less than

resolution than .0002mm. Therefore, any entry less than
.0002mm exceeds the resolution of an encoder with .0002mm

.0002mm exceeds the resolution of an encoder with .0002mm

.0002mm exceeds the resolution of an encoder with .0002mm
resolution.

resolution.

Scroll through the setup menu until Display is highlighted.

The following data entry fields are displayed, MM Disp Res (milli-
meter display resolution), Inch Disp Res (inch display resolution),
DMS Disp Res (degrees, minutes, seconds display resolution), DD
Disp Res (decimal degrees display resolution). Each of these fields
are supervisor level procedures and require the supervisor pass-
word to be entered prior to changing.

The following option selection fields are displayed, Startup Linear,
Startup Angular, Radix, and Current Angular. Each of these fields
are user level procedures and can be changed without entering
the supervisor password.

Press the right cursor key to select items in the right portion of
the screen.
