3-3

Using the
Setup menu

To select from the Setup menu scroll through the list using the up
or down arrow keys and highlight the desired setup screen. When
a setup screen is highlighted, associated data entry fields and op-
tion selection fields appear on the right portion of the screen and
can be configured or changed using arrow keys, softkeys, com-
mand keys, and numeric keypad.

Setup Instructions

Selecting and configuring system parameters are explained in the
Using the Setup menu section of this chapter. Configure the TC200
prior to using it the first time and when tool measurement, re-
porting, or data communication requirements change.

To access the setup menu, press the menu key and then press the
setup softkey.
