Operation of the System
The CopperHead 3050 Base Station Digital Display
DIAG/TEMP
47C
Temperature display in Centigrade for Base Station circuit
board
DIAG/TEMP
PS
The Power Supply (PS) temperature will be again
displayed
DIAG/TEMP
TEMP
Repeats that the display is in the TEMP sub-mode
DIAG/TEMP
36C
Temperature display in Centigrade for Power Supply
circuit board
Note: the PS temperature has dropped one degree
This display cycle repeats until the Display Mode Selector
is pushed
DIAGNOSTIC MODE Power Supply Voltage Status (POWER)
DIAG/POWER
A quick push of the Display Mode Selector advances to
the Power (POWR) diagnostic sub-mode. Digital Display
Characters are Green when all power levels are normal
and Red when any power level is outside normal level
DIAG/POWER
POWR
Indicates the display is in the POWER sub-mode
DIAG/POWER
BASE
Indicates that the Base Station main controller board is
being measured
DIAG/POWER
POWER
Indicates the display is in the POWER sub-mode
DIAG/POWER
OK
Indicates that the item is in an OK State
DIAG/POWER
DISP
Indicates that the LED Display controller board is being
measured
DIAG/POWER
POWER
Indicates the display is in the POWER sub-mode
DIAG/POWER
OK
Indicates that the item is in an OK State
DIAG/POWER
CHAR
Indicates that the Four-character controller board is being
measured
DIAG/POWER
POWR
Indicates the display is in the POWER sub-mode
DIAG/POWER
OK
Indicates that the item is in an OK State
DIAG/POWER
AUD
Indicates that the Audio controller board is being
measured
DIAG/POWER
POWR
Indicates the display is in the POWER sub-mode
DIAG/POWER
OK
Indicates that the item is in an OK State
DIAG/POWER
VBS
Indicates that the VBS (analog Video) controller board is
being measured
DIAG/POWER
POWR
Indicates the display is in the POWER sub-mode
DIAG/POWER
OK
Indicates that the item is in an OK State
DIAG/POWER Exception
DIAG/POWER
ERR
Instead of OK, the display will show ERR if a power level is
outside of normal - ERR is followed by a Hexadecimal
code. Please note the error code. A list of Hexadecimal
codes is available in a Technical Bulletin at
.
DIAGNOSTIC MODE Microcontroller Board Revision Version (REV)
Display Mode
Readout
Base Station Digital Display Activity Explanation
