44
Connection of the System
Connections to the CopperHead 3050 Camera Unit
6 Audio 2 Input
XLR 3 Pin Female Connector – Line level audio input. Typically fed by a short
audio jumper cable from the Camera Audio 2 output
7 HD-SD/SDI Input
BNC Connector – Carries camera video from the Camera to the Camera Unit.
This requires a short BNC jumper cable between the Camera Unit and the
Camera.
8 HD-SD/SDI Outputs #1 & #2
BNC Connector – Carries return video from the Base Station to the Camera
Unit. Typically this will feed a camera viewfinder or an HD viewing monitor at
the camera location.
9 VBS In
BNC Connector – Carries SD Analog video from the Camera to the Camera
Unit. This requires a short BNC jumper cable between the Camera Unit and
the Camera. Can be used to provide technical monitoring from camera as
with superimposed camera menus and other information.
10 VBS Out
BNC Connector – Carries SD Analog video from the Base Station the Camera
Unit. Typically this will feed an analog viewing monitor at the camera
location.
11 Ethernet Out
RJ45 Connector – Carries IP Data. Typically connects to a Laptop computer or
perhaps a wireless access point at the camera location. Any IP traffic
controlled equipment can be handled through this signal path.
12 Intercom Headset Connector
Mini-phone Jack – Provides listen only Intercom audio.
13 Power Wafer Connector
Multi-Pin Connector C – Supplies power to the Camera Unit from the Power
Wafer (if so configured). This cable is supplied with the Power Wafer Power
Adaptor.
14 Fiber Connector
Swivel Mounted Fiber Optic Cable receptacle – specific connector depends
on your configuration.
Diagram # Description
