Physical installation, 4 physical installation – Grass Valley 3050 CopperHead User Manual
Page 37
31
Physical Installation
This chapter describes the physical installation of the CopperHead 3050 Transceiver
System.
Mounting the CopperHead 3050 Camera Unit to the Camera . . . . . . . . . . . . . . . . . . . . . . . . . 32
Mounting the Power Wafer Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Relocation of the CopperHead 3050 Base Station Fiber connector . . . . . . . . . . . . . . . . . . . . . 34
