5.5.4 Touch Screen
In this menu you can make touch screen specific adjustments. The OSD
of the Draco major supports the control by a touch screen.
You have the following possibility to access the menu:
USB-HID based touch screen protocols are supported.
Support of manufacturer specific protocols by request.
 Press key .
Menu Configuration – Touch
In this mask you can do the calibration of your touch screen for every
single console. For this purpose you are required to click at least two
times at a point at the top left and at the bottom right. After that you will
have the opportunity to check the calibration, to save it or to abort it.
The calibration has to be done for every single touch screen at any
console.
