Draco major
42 2011-10-11
4.3.7 Training System 30
If you want to use the Draco major matrix with the 'Training System 30'
operation mode, the access is slightly limited, but still comfortable.
The following functions are possible:
 The teacher can receive the screen content of every single student,
but he cannot take over control.
 The screen content of the teacher can be displayed on an additional
monitor (e.g. a projector).
 The screen content of every single student can be displayed on an
additional monitor (e.g. a projector).
Training System 30
A Students' area
B Teacher's area
1 Student's work station (source console)
2 CPU Unit
3 Interconnect cable
4 Draco major matrix
5 CON Unit
6 Projector (optional)
