Configuration
2011-10-11 121
Direct Switching of Video
1. Start Command Mode with the 'Hot Key'.
For control, the LEDs Shift and Scroll flashes at the keyboard, if
command mode is activated.
2. Enter the number of the new CPU port and confirm with .
At the same time the Command Mode is closed and the console is
connected to the new CPU with video only.
You can only switch to not used and allowed CPUs with the 'Hot Keys'.
The options Force Connect and Force Disconnect as well as the
restrictions of the User Matrix and CON Matrix are taken into account.
'Hot Keys' are only supported, if neither Enable Login nor the User
Matrix
is selected and the user is logged in the OSD.
6.1.2 Scan Mode
The Scan Mode offers the possibility to show video signals of the different
CPUs fast and without delay and offers switching in between without
continuously using the 'Hot Key'. The switching between two video signals
can even take place within one frame.
1. Start command mode with the 'Hot Key'.
For control, the LEDs Shift and Scroll flashes at the keyboard, if
command mode is activated.
2. Press the key and hold it down.
3. Enter the numbers of the various CPUs with the keyboard and
immediately switch to the video signal of the respective CPU after
entering the port number.
Optimal results can be achieved by the use of as identical resolutions as
possible. This contributes to a smooth and delay less function of the scan
mode.
