Draco major
118 2011-10-11
5.8 Firmware Update
The firmware of the matrix can be updated in this menu. You have the
following possibility to access the menu:
Only use computers to update the matrix that are self-sustaining and not
integrated in the KVM extender / matrix setup.
1. Select
Administration > Update Firmware
in the task area.
Menu Administration – Update Firmware
2. Select the directory in the lower part of the working area in which the
update file can be found.
Open the file defaults.cfg and insert in the parameter upd.dir the
directory from which the update files should be standardly sourced.
3. Select those modules in the list that have to be updated and enable
the respective checkbox in the column Update.
4. Start the update by pressing the button Update in the lower part of
the working area.
