Draco major

44

2011-10-11

4.3.8

Crosspoint Matrix

The use of the 'Crosspoint Switch' function allows a flexible performance
of the switching functions. This operation mode is generally used to switch
up to 32 sources (Computer, CPU) and up to 16 consoles.

Reverse Mode

In 'reverse mode', up to 16 sources (computer, CPU) can be switched to
32 consoles.

The switching can be done in a number of different ways:

By the OSD of a console that is connected to the CON port

By a PC and the Java tool

By switching commands in combination with the network connection

By switching commands in combination with the serial connection

1

2

3

5

3

6

4

Crosspoint Matrix
