Draco major
90 2011-10-11
You can select between the following settings:
Field Selection Function
Name
Text Name of the console connected to this
port
SH
Single-Head port
DH
Dual-Head port
QH Quad-Head port
0U
USB-2.0 port
1U
Single-Head port with USB 2.0 port
Type
3U Triple-Head port with USB 2.0 port
VAR
OSD embedded to current resolution
(default)
OSD display screen filling:
800
800x600
1024
1024x768
1280
1280x1024
1600
1600x1200
OSD
1920
1920x1200
CPU
Port
number Number of the CPU that is connected to
this console or will be connected after
saving
