Draco major

24

2011-10-11

The following information is shown in this menu:

Field

Description

Output

Name of CON port

Input

Name of CPU port connected to the output signal
(KM) of the CON port.


3.7.4

Network Status

The current network configuration is shown in this menu.

You have the following possibilities to access the menu:

The following information is shown in this menu:

Field

Description

DHCP

Display that shows, if the network settings are set
dynamically (YES or NO).

IP Address

Display of the IP address as entered manually or
set by DHCP

Subnet Mask

Display of the subnet mask as entered manually or
set by DHCP

Gateway

Display of the gateway address as entered
manually or set by DHCP

MAC ID

Display of the MAC address of the matrix

Errors

Number of data packets with errors

Dropped

Number of dropped data packets

Station

Number of data packets for single receivers

Broadcast

Number of data packets for all receivers

Bytes

Number of received/transmitted bytes
