03/07/03 6-1
Section 6
PUMP/DISPENSER MANUAL TEST
1.
Verify that the general guidelines listed below were met when installing the system’s pumps
and dispensers.
Suction
Pumps
The Series 1000 System is capable of directly driving pump motors up to 3/4 HP at 115 VAC
or 230 VAC. A starter relay must be used with pump motors over 3/4 HP. A separate circuit
breaker should be supplied for each pump to meet the current requirements and to allow for
isolated control with the circuit breaker panel in case of problems.
Dispensers
The Series 1000 System is capable of directly driving submersible pumps up to 3/4 HP at 115
VAC or 230 VAC. A separate circuit breaker should be supplied for each dispenser in cases
where it will directly drive the submersible pump. A dispenser with a submersible pump rated
over 3/4 HP will require the use of a submersible starter relay. Dispensers may be grouped
together on a single breaker when the submersible pump has its own breaker. It is
recommended that no more than two dispensers be powered from one breaker to maintain
isolated control with the circuit breaker panel in case of problems.
2.
Manual Override Test: The pumps and/or dispensers should be tested to verify the AC
wiring. DO NOT TURN ON THE SYSTEM POWER DURING THESE TESTS! The steps
below indicate the proper procedure for testing and the expected results. If any of these tests
fail, correct the wiring and the perform the test again. See Figure 5-1 for location of the
override switches.
a. Turn on the breakers for all pumps and/or dispensers. DO NOT TURN ON THE
BREAKER FOR THE SERIES 1000.
CAUTION
AC power is present on the terminal blocks in the pedestal. Electrical shock
may occur if the operator comes in contact with these connections.
b. Place the system override switch for Hose 1 in the MANUAL position.
c. Turn on Hose 1. After completing reset, the hose should be able to dispense product.
d. Turn on all other hoses. No other hoses beside 1 should activate.
e. Turn off all hoses.
f. Place the system override switch, for Hose 1 in the OFF position.
g. Repeat
Steps b through f for all remaining hoses. Substitute the hose number being
tested for Hose 1.
