Installing your car stereo 23
Chevrolet
Astro 1985-1989
GMC
Safari 1985-1989
To install your car stereo:
1 Disconnect the negative battery terminal to prevent an accidental short circuit.
2 Remove three screws from the top of the dash trim bezel.
3 Open the glove box, then remove two 10 mm bolts from the lower edge of the trim
bezel.
4 Pull the console trim forward, then remove two exposed 10 mm bolts. Carefully unclip
the trim bezel, then remove it.
5 Remove two 7 mm screws from the factory head unit, then disconnect the wiring.
6 Cut and remove all mounting tabs on bracket 3 except the A tabs. Each mounting tab
has a letter stamped on the back of the tab. Cut the tabs with the blade pointed away
from you and your fingers.
7 Go to “Completing the installation” on page 76.
A
A
