Dynex DX-G1113 - Manual (Page 16)

16 Installing your car stereo
Buick
Skyhawk 1982-1989
Oldsmobile
Firenza 1982-1989
To install your car stereo:
1 Disconnect the negative battery terminal to prevent an accidental short circuit.
2 Remove the glove box by removing the door strap wire clip and four screws.
3 Remove the two screws below the cigarette lighter and three screws below the
steering column.
4 Remove one screw from top-left of the factory head unit, then unclip the dash trim
bezel.
5 Remove the hardware that secures the factory mounting brackets to the factory head
unit. Remove and retain the brackets.
6 Go to “Completing the installation” on page 76.
2
S10 shown
as example
