3. Board Components Reference
This chapter lists the component reference and manufacturing information of all the
components on the Arria V SoC development board.
Table 3–1. Component Reference and Manufacturing Information
Board
Reference
Component
Manufacturer
Manufacturing
Part Number
Manufacturer
Website
U41
Arria V SoC FPGA F1517, 462,000
LEs, lead free
Altera
Corporation
5ASTFD5K3F40I3
U27
MAX V CPLD 5M2210 System
Controller
Altera
Corporation
5M2210ZF256
U61
High-Speed USB peripheral controller
Cypress
CY7C68013A
D9-D16,
D20-D24,
D33-D36,
D38-D43,
Green LEDs
Lumex Inc.
SML-LXT0805GW-TR
D39
Red LED
Lumex Inc.
SML-LXT0805IW-TR
D37
Blue LED
Lumex Inc.
SML-LX0805USBC-TR
SW2, SW4
Four-position DIP switches
C&K Components/
ITT Industries
TDA04H0SB1
SW1, SW3
Eight-Position DIP switch
C & K Components
TDA08H0SB1
S1-S9,
S12-S14
Push buttons
Panasonic
EVQPAC07K
J17
External Mictor 38-pin connector
Tyco Electronics
2-767004-2
X4
50 MHz 1.8-V oscillator
ECS, Inc.
ECS-3518-500-B-xx
X5
125.00 MHz LVDS crystal oscillator
Epson
EG-2121CA
125.0000M-LGPNL3
U35
Programmable quad clock, I
2
C 0x70,
defaults LVDS 156.25 MHz, 25 MHz,
25 MHz, 100 MHz default
Silicon Labs
Si5338C-A01917-GM
U42
IC - Pre-programmed (quad clock
generator), 25, 25, 100, 100 MHZ
LVCMOS, 1.8V, 2.5V
Silicon Labs
Si5335A-B02062-GM
U59
IC - PCIE Gen 1/2 dual output clock
generator
Silicon Labs
SI52112-B3-GM2
U30
1 to 3 single-ended clock buffer
Silicon Labs
SL18860DC
X2
Programmable LVDS clock 100M
defaults
Silicon Labs
570FAB000973DG
X3
Programmable LVDS clock 148.5M
defaults
Silicon Labs
571FAB000973DG
J29
2×7 pin LCD socket strip
Samtec
TSM-107-07-G-D
2×16 character LCD, 5×8 dot matrix
Lumex Inc.
LCM-S01602DSR/C
