D12
FMC_LA_TX_N2
F27
2.5-V CMOS
FMC data bus
H14
FMC_LA_TX_N3
P28
2.5-V CMOS
FMC data bus
D15
FMC_LA_TX_N4
A27
2.5-V CMOS
FMC data bus
H17
FMC_LA_TX_N5
N25
2.5-V CMOS
FMC data bus
D18
FMC_LA_TX_N6
L27
2.5-V CMOS
FMC data bus
H20
FMC_LA_TX_N7
P21
2.5-V CMOS
FMC data bus
H23
FMC_LA_TX_N9
T21
2.5-V CMOS
FMC data bus
H26
FMC_LA_TX_N10
A24
2.5-V CMOS
FMC data bus
H29
FMC_LA_TX_N12
T22
2.5-V CMOS
FMC data bus
D27
FMC_LA_TX_N13
L24
2.5-V CMOS
FMC data bus
H35
FMC_LA_TX_N14
H25
2.5-V CMOS
FMC data bus
H38
FMC_LA_TX_N15
T24
2.5-V CMOS
FMC data bus
G13
FMC_LA_TX_N16
T23
2.5-V CMOS
FMC data bus
H32
FMC_LA_TX_N17
K23
2.5-V CMOS
FMC data bus
H7
FMC_LA_TX_P0
H27
2.5-V CMOS
FMC data bus
H10
FMC_LA_TX_P1
J26
2.5-V CMOS
FMC data bus
D11
FMC_LA_TX_P2
E27
2.5-V CMOS
FMC data bus
H13
FMC_LA_TX_P3
N28
2.5-V CMOS
FMC data bus
D14
FMC_LA_TX_P4
A26
2.5-V CMOS
FMC data bus
H16
FMC_LA_TX_P5
M25
2.5-V CMOS
FMC data bus
D17
FMC_LA_TX_P6
K27
2.5-V CMOS
FMC data bus
H19
FMC_LA_TX_P7
N21
2.5-V CMOS
FMC data bus
H22
FMC_LA_TX_P9
R21
2.5-V CMOS
FMC data bus
H25
FMC_LA_TX_P10
A23
2.5-V CMOS
FMC data bus
H28
FMC_LA_TX_P12
R22
2.5-V CMOS
FMC data bus
D26
FMC_LA_TX_P13
K24
2.5-V CMOS
FMC data bus
H34
FMC_LA_TX_P14
G25
2.5-V CMOS
FMC data bus
H37
FMC_LA_TX_P15
R24
2.5-V CMOS
FMC data bus
G12
FMC_LA_TX_P16
R23
2.5-V CMOS
FMC data bus
H31
FMC_LA_TX_P17
J23
2.5-V CMOS
FMC data bus
F1
FMC_M2C_PG
—
2.5-V CMOS
Power good input
H2
FMC_PRSNT
K25
2.5-V CMOS
FMC module present
C30
FMC_SCL
J22
2.5-V CMOS
Management serial clock line
C31
FMC_SDA
D23
2.5-V CMOS
Management serial data line
D29
JTAG_MUX_TCK
AV34
2.5-V CMOS
JTAG chain clock
C23
LMK_CLK_FMC_N
—
2.5-V CMOS
Alternate mezzanine-bound clock (from LMK device)
C22
LMK_CLK_FMC_P
—
2.5-V CMOS
Alternate mezzanine-bound clock (from LMK device)
Table 2–21. FMC Port A Pin Assignments, Schematic Signal Names, and Functions (Part 4 of 5)
Board
Reference
(J26)
Schematic
Signal Name
Arria V SoC
Pin Number
I/O Standard
Description
