2–28

Chapter 2: Board Components

General User Input/Output

Stratix IV E FPGA Development Board Reference Manual

May 2011

Altera Corporation

Table 2–29

lists the seven-segment LED display component reference and the

manufacturing information.

Character LCD

The development board contains a single 14-pin 0.1" pitch dual-row header that
interfaces to a 16 character × 2 line Lumex character LCD display. The LCD has a
14-pin receptacle that mounts directly to the board's 14-pin character LCD header
(J23), so it can be easily removed for access to components under the display. You can
also use the character LCD header for debugging or other purposes.

Table 2–32

summarizes the character LCD pin assignments. The signal names are

relative to the Stratix IV E FPGA.

U29.7

G

SEVEN_SEG_G

2.5-V

K29

U29.5

DP

SEVEN_SEG_DP

L29

U29.1

DIG_SEL1

SEVEN_SEG_SEL1

M26

U29.10

DIG_SEL2

SEVEN_SEG_SEL2

R28

U29.4

DIG_SEL3

SEVEN_SEG_SEL3

J29

U29.6

DIG_SEL4

SEVEN_SEG_SEL4

R27

U29.13

DIG_MINUS

SEVEN_SEG_MINUS

K30

Table 2–30. Seven-Segment LED Display Pin Assignments, Schematic Signal Names, and Functions

Board Reference

Description

Schematic Signal Name

I/O Standard

Stratix IV E Device

Pin Number

Table 2–31. Seven-Segment LED Display Component Reference and Manufacturing Information

Board

Reference

Description

Manufacturer

Manufacturer

Part Number

Manufacturer Website

U29

Quad digit seven-segment LED

Lumex Inc.

LDQ-M2212RI

www.lumex.com

Table 2–32. Character LCD Header Pin Assignments, Schematic Signal Names, and Functions

Board Reference

Description

Schematic Signal Name

I/O Standard

Stratix IV E Device

Pin Number

J23.1

Power

5.0V

J23.2

Ground

GND

J23.3

Ground

GND

J23.4

LCD data or command select

LCD_D_Cn

2.5-V

AF13

J23.5

LCD write enable

LCD_WEn

AF14

J23.6

LCD chip select

LCD_CSn

AM9

J23.7

LCD data bus

LCD_DATA0

AP9

J23.8

LCD data bus

LCD_DATA1

AP11

J23.9

LCD data bus

LCD_DATA2

AN10

J23.10

LCD data bus

LCD_DATA3

AP10

J23.11

LCD data bus

LCD_DATA4

AE13

J23.12

LCD data bus

LCD_DATA5

AE14
