InfoStation 12-Bay RAID User's Guide - Rev. D00 StorCase Technology, Inc.
RAID Controller Configuration 67
2 SCSI Params
(For SCSI-to-SATA version only)
NOTE: Configuration changes made in the SCSI Params menu must be saved and the
RAID controller restarted before changes can take effect. Refer to section "5
NVRAM" of this User's Guide for further information.
SCSI Params Menu
2.1 Primary SCSI
This function enables the user to configure Primary SCSI settings.
2.1.1 Set SCSI ID
Select either 0-14 or Multiple (default =0). ID7 is reserved for the SCSI card.
2.1.2 Speed
Select either Ultra320, Ultra3, Ultra2, Ultra, or Fast. Refer to Table 7 for settings.
2.1.3 Wide
Select either Enable (default) or Disable. Refer to Table 7 for settings.
2 SCSI Params 2.1 Primary SCSI 2.1.1 Set SCSI ID
2.1.2 Speed
2.1.3 Wide
2.1.4 LUN Map
2.2 Secondary
SCSI*
2.1.5 QAS
* Submenus are the same
as 2.1 Primary SCSI
0-14 / Multiple
Enable / Disable
Ultra320 / Ultra3 /
Ultra2 / Ultra / Fast
Enable / Disable
Match slices in
existing arrays
(up to 128 LUNs)
Enable / Disable
