InfoStation 10-Bay RAID User's Guide - Rev. E00
StorCase Technology, Inc.
RAID Controller Configuration
65
3 RS232 Params
3 RS232 Params
3.1 Modem Port
3.1.1 Baud Rate
3.1.2 Stop Bit
3.1.3 Data Bit
3.1.4 Parity Bit
3.2 Terminal Port*
* Submenus are the same
as 3.1 Modem Port
2400, 4800, 9600,
14400, 28800, 38400,
57600, or 115200
1 / 2
None / Odd / Even
7 / 8
Modem Port Menu
3.1 Modem Port
This function enables the user to set the Baud Rate, Stop Bit, Data Bit, and Parity parameters
for the modem port to match those of the modem. Refer to your modem manufacturer's
documentation for further information.
3.1.1 Baud Rate
Select either 2400, 4800, 9600, 14400, 19200, 28800, 38400, 57600, or 115200 (default).
3.1.2 Stop Bit
Select either 1 (default) or 2.
3.1.3 Data Bit
Select either 7 or 8 (default).
3.1.4 Parity
Select either None (default), Odd, or Even.
