Page 67

54
RAID Controller Configuration
StorCase Technology, Inc.
InfoStation 10-Bay RAID User's Guide - Rev. E00
RAID Controller Configuration Overview
Refer to pages 54-76 for an overview of the InfoStation RAID configuration options. The
following sections contain detailed information regarding each option and all their functions.
1 RAID Params
NOTE:
Configuration changes made in the RAID Params menu must be saved and the
controller restarted before changes can take effect. Refer to section "5
NVRAM" of this User's Guide for further information.
1 RAID Params
1.1 Array 1
1.2 Array 2*
1.3 Array 3*
1.4 Array 4*
1.1.1
Array 1
Re-conf RAID
1.1.2 RAID Level
1.1.3 Disk
Number
1.1.4 Slice
No / Yes
0 / 1 / 3 / 5 / 0+1 /
30 / 50 / None
Choices dependent
on RAID level
Create slices,
set slice size
* Submenus are the same as 1.1 Array 1
1.B Performance
Random /
Sequential
Enable / Disable
1.A Write Buffer
1.9 Stripe Size
1024 / 512 / 256 /
128 / 64 / 32 / 16 / 8
1.5 Array 5*
1.6 Array 6*
1.7 Array 7*
1.8 Array 8*
