Configuring the RAID Controller
There are two aspects to configuring the RAID controller:
• Configuration of the RAID system and communication parameters
• Setting up and configuration of arrays within the RAID system
Users are advised to configure the system first, then the arrays.
The following sections provide instructions on how to setup a RAID configuration for the first
time.
Choose one of the following methods:
RAID Configuration via Data Master GUI
Page
•
Data Master Connection (Read FIRST before proceeding to RAID Setup)
21
•
Quick RAID Setup (One array using all disks installed)
26
•
Customized RAID Setup (Multiple arrays & custom number of disks in an array) 28
•
Partitions
30
•
LUN Mapping
36
•
Deleting an Array
39
RAID Configuration via Monitor Utility (HyperTerminal)
Page
•
HyperTerminal Connection (Read FIRST before proceeding to RAID Setup)
40
•
Quick RAID Setup (One array using all disks installed)
43
•
Customized RAID Setup (Multiple arrays & custom number of disks in an array) 44
•
Partitions
46
•
LUN Mapping
50
•
Deleting an Array
53
