Appendix A - Specifications/Dimensions

StorCase Technology, Inc.

InfoStation 10-Bay RAID User's Guide - Rev. E00

Figure A-1: InfoStation Physical Dimensions

(Dimensions are for reference only)

Top View

Right Side View

Front View

1.70

(43.2mm)

17.49

(444.2mm)

18.98

(482.1mm)

19.80

(502.9mm)
