StorCase Technology InfoStation 10-Bay 1U Ultra320/SATA User Manual
Page 30
InfoStation 10-Bay RAID User's Guide - Rev. E00
StorCase Technology, Inc.
FC Configurations
17
Figure 7B: Typical Dual FC Loops Connection to InfoStation
(S10K1011 shown)
PC
(InfoMon)
To FC-AL
(Loop A)
To FC-AL
(Loop B)
PC
(HyperTerminal
or Data Master)
External
Modem
Cascade to
another InfoStation
Cascade to
another InfoStation
