CAUTION: Multicast VLAN Config settings will be restored to defaults if the

Switch is restarted and you have not selected Save Config from
the main menu and saved your running configuration to non-
volatile memory.

NOTE: The Router Port (Multicast Server) should be in the Multicast

VLAN, if it is not, the member Ports cannot
receive Multicast streams.

NOTE: The Multicast VLAN will not take effect unless you first complete

the configuration for the corresponding VLAN and Ports on the
802.1Q VLAN page.

NOTE: The Link Type of the possible Member Ports in the Multicast VLAN

must be set to GENERAL..

NOTE: Configure the Link Type of the Router Port (Multicast Server) in

the Multicast VLAN as TRUNK or configure the Egress Rule as TAG
and the Link Type as GENERAL otherwise the member Ports in the
Multicast VLAN cannot receive Multicast streams.

NOTE: After a Multicast VLAN is created, all IGMP packets will be processed

only within the Multicast VLAN.

Configuration procedure:

Step Operation

Description

Enable IGMP Snooping

Enable IGMP Snooping globally on the Switch and
for the Port on

Multicast-IGMP Snooping-Snooping

Config and Port Config page.

Create a Multicast VLAN

Create a Multicast VLAN and add all the potential
Member Ports and Router Ports to the VLAN on the
VLAN>>802.1Q VLAN page.

Configure the Link Type of the potential Member
Ports as GENERAL.

Configure the Link Type of the Router Ports as
TRUNK or configure the Egress Rule as tagged and
Link Type as GENERAL.
