Side Panel Removal
Note: The side panel(s) must be taken off to remove the Axiom from its
pallet.
1.
Remove and save the two Phillips screws on the front edge of the side panel.
2.
Pivot the front of the panel away from the cabinet. Lift the panel straight up and
pull the panel straight away from the cabinet to release the rear of the side panel
from its hinge.
Side Panel Installation
1.
Install the side panel by inserting both back panel hooks into the side panel
slots.
2.
Ensure both panel slots are completely seated on the hooks.
3.
Pivot the front of the panel toward the cabinet. Secure the panel by installing
and tightening the two Phillips screws.
Corner Post Lower Trim
The corner post lower trim pieces are secured to the corner post by a single machine
screw and lock nut. When properly positioned, the trim piece fits tightly against corner
post. See Figure 6-3.
Figure 6-3
Use a 3/8” wrench and Phillips
screwdriver to adjust the corner post
screw.
Note: DO NOT over tighten the screw;
damage to the trim piece may occur.
