QuickChart – Axiom Type C1 BSCs – Imperial Units
Model
30441
30448
30461
30468
Type
C1
C1
C1
C1
Cabinet Size (in feet)
4
4
6
6
Sash Opening (inches)
10
8
10
8
Starting Serial #
1503_
1503_
1503_
1503_
Downflow Data
Nominal Avg. Downflow (FPM)
65+/-5
65+/-5
55+/-5
55+/-5
grid # of points (rows x columns)
24 (3x8)
24 (3x8)
36(3x12)
36(3x12)
Grid distance from back & sides
6.0
6.0
6.0
6.0
Distance between rows
5.55
5.75
5.55
5.75
Distance between columns
5.21
5.21
5.50
5.50
Inflow Data
Nominal Average Inflow (FPM)
105+/-5
105+/-5
105+/-5
105+/-5
Sash Open Area (Sq. Ft)
3.37
2.69
5.03
4.03
Nominal Avg. Exhaust Vol. (CFM)
354
283
529
423
Avg. Exhaust Vol. Range (CFM)
337-371
269-296
503-553
403-443
Secondary Inflow Data
Sash Opening Template
1
4+
4+
6+
6+
Sensor distance (inches)
2
3.25
3.25
4
4
# of Test points
8
8
12
12
Test point location
*
*
*
*
Nominal Avg. Inflow Vel. (FPM)
354
283
289
231
Avg. Inflow Vel. Range (FPM)
312-344
249-274
252-277
202-222
Correction Factor (CF)
1.08
1.08
2
2
Avg. Inflow Volume (CFM)
337-371
269-296
503-553
403-443
Sash Open Area (Sq. Ft)
3.37
2.69
5.03
4.03
Inflow Velocity Range (FPM)
100-110
100-110
100-110
100-110
Supply HEPA Data
Air Displacement (CFM)
530
530
660
660
Laskin Nozzles needed
1
1
1
1
Theoretical aerosol conc. (ug/l)
3
25
25
20
20
Width x Depth x Height (in.)
4
48x18x3.06
48x18x3.06
72x18x3.06
72x18x3.06
Performance (CFM)
445
445
665
665
Performance (Pressure in. H
2
O)
<.45”
<.45”
<.42”
<.42”
Labconco P/N
3838401
3838401
3838403
3838403
Exhaust HEPA Data
Air Displacement (CFM)
354
283
529
423
Laskin Nozzles needed
1
1
1
1
Theoretical aerosol conc. (ug/l)
3
38
48
26
32
Width x Depth x Height (in.)
4
26x18x5.88
26x18x5.88
48x18x5.88
48x18x5.88
Performance (CFM)
354
354
529
52
Performance (Pressure in. H
2
O)
<0.3
<0.3
<0.3
<0.3
Labconco P/N
3838501
3838501
3838503
3838503
Exhaust Volume Data
DIM Exhaust Volume (CFM)
5
400
323
570
463
Traverse Exhaust Volume (CFM)
6
480
387
684
556
Differential Pressure (in. H
2
0)
7
0.3
0.3
0.3
0.3
IRV Inflow Range (CFM)
8
20-100
20-100
20-100
20-100
Nominal IRV Slot Velocity (FPM)
240-260
240-260
240-260
240-260
Nominal IRV Slot Volume (CFM)
50
50
50
50
Supply Motor/Blower Data
Motor HP
1/3
1/3
1/3
1/3
Exhaust Motor/Blower Data
Motor HP
1/3
1/3
1/3
1/3
Fluorescent Lamp Data
Fluorescent Lamps (2 each)
F32T8 TL741
F32T8 TL741
F40T8 SP41
F40T8 SP41
Fluor. Lamp Labconco Part #
9721900
9721900
9721903
9721903
Fluor. Ballast Labconco Part #
3838100
3838100
3838100
3838100
