Quickstart
How do I recalibrate the
 blower speed
 filter life gauge
 airflow sensor reading
of the Axiom?
1. Press the Menu button.
2. Press the ▼ button until the Services option is highlighted (it will
turn yellow).
3. Press OK/Mute to enter the Services menu screen.
4.
Press the ▼ button until the Calibration option is highlighted (it
will turn white).
5. Press OK/Mute to start the calibration procedure.
6.
You will see a warning screen alerting you that you are about to
alter the BSC’s settings.
7. Press OK/Mute to input the password.
8.
When requested for the password press Light , UV light ,
Timer , Timer then OK/Mute .
9.
If the password is properly entered, the first certification screen
will display the supply blower motor’s PWM setting. Press the ▲
or ▼ button to increase or decrease the blower speed as
needed. When the speed is set properly, press the OK/Mute
button to lock the new blower speed setting, and continue to the
filter life screen.
MAIN MENU
1. MyLogic TM
2. Set t ings
3. Service
 
or t o choose,
OK t o select , MENU t o escape
or t o choose,
OK t o select , MENU t o ret urn
 Current Settings
Restore Default
Diagnostics
Configuration
Calibration
 
Service
ATTENTION!
The following screens are used
to alter the operation of the
Logic. They should only be used
by a qualified certifier as part
of the certification process.
Calibrat ion
OK t o proceed, MENU to return
PASSWORD:
Calibrat ion
The ECM set t ing is: 80
The current RPM is: 1050
The average RPM is: 1020
Calibration
Supply Fan Speed
or t o change mot or speed,
OK t o select , MENU t o escape
 
