Labconco Type C1 Biosafety Cabinet Models 30468 User Manual
Page 3

Product Service 1-800-522-7658
3
Table of Contents
Introduction
7
Contacting Labconco
7
Section One – Background Information
QuickStarts
8
What’s the password for the Axiom?
9
How do I calibrate blower speed, filter life & airflow sensor? 10-11
How do I see the current settings?
12
How do I change the configuration?
13-14
How do I run a diagnostic on the:
Sash position switches?
15
Keypad, relays and contact?
16
Inlet Relief Valve?
17
Airflow Sensor?
18
How do I set up automatic operation of the blower & lights?
19
Axiom Filter Life Gauge Operation and Resetting for Local Conditions
20
QuickCharts
Axiom Type C1 Purifiers
21-23
Identifying Axiom Models
24
Serial Number Tags
25
Model Numbering System
26
Axiom Data Plate
27
Final Inspection and Test Report
28
Theory of Operation
Background
29
Airflow Patterns and Features
29
Chem-Zone
TM
Directly Exhausted Work Zone
30
Inlet Relief Valve
31
Exhaust System
31
Exhaust System Alarm
32
Airflow Patterns of Axiom
33
ECM Motor
34-35
Electronics
35-36
Section Two – Installation Requirements
Prerequisites
37
Space Requirements
37
Clearance
37
Location Requirements
38
If You Intend to Connect the Axiom to an Exhaust System
39-41
Electrical Requirements
42
Service Line Requirements
43
