Specifications
163
¢ Audio section
• Power amplifier
Rated output:
Front:
140 W + 140 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
165 W + 165 W (6 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
Center:
140 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
165 W (6 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
Surround (A, B):
140 W + 140 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
165 W + 165 W (6 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
Surround Back:
140 W + 140 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
165 W + 165 W (6 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
Dynamic power:
180 W x 2 ch (8 Ω/ohms)
280 W x 2 ch (4 Ω/ohms)
Output terminals:
Front, Center, Surr. Back
6 ~ 16 Ω/ohms
Surround:
A or B
6 ~ 16 Ω/ohms
A + B
8 ~ 16 Ω/ohms
• Analog
Input sensitivity / input impedance:
200 mV / 47 kΩ/kohms
Frequency response:
10 Hz ~ 100 kHz: +0, –3 dB (DIRECT mode)
S/N:
102 dB (DIRECT mode)
Distortion:
0.005 % (20 Hz ~ 20 kHz) (DIRECT mode)
Rated output:
1.2 V
• Digital
D/A output:
Rated output — 2 V (at 0 dB playback)
Total harmonic distortion — 0.005 % (1 kHz, at 0 dB)
S/N ratio — 110 dB
Dynamic range — 108 dB
Digital input:
Format — Digital audio interface
• Phono equalizer (PHONO input — REC OUT)
Input sensitivity:
2.5 mV
RIAA deviation:
±1 dB (20 Hz to 20 kHz)
S/N:
74 dB (A weighting, with 5 mV input)
Rated output / Maximum output:
150 mV / 8 V
Distortion factor:
0.03 % (1 kHz, 3 V)
¢ Video section
• Standard video terminals
Input / output level and impedance:
1 Vp-p, 75 Ω/ohms
Frequency response:
5 Hz ~ 10 MHz — +0, –3 dB
• S-Video terminals
Input / output level and impedance:
Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
C (color) signal — 0.286 Vp-p, 75 Ω/ohms
Frequency response:
5 Hz ~ 10 MHz — +0, –3 dB
• Color component video terminal
Input / output level and impedance:
Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
P
B
/C
B
signal — 0.7 Vp-p, 75 Ω/ohms
P
R
/C
R
signal — 0.7 Vp-p, 75 Ω/ohms
Frequency response:
5 Hz ~ 100 MHz — +0, –3 dB
