118
Advanced Setup – Part 1
Volume Limit:
Set the upper limit for the volume for the different
zones.
• –20 dB, –10 dB, 0 dB:
The volume cannot be increased above the
selected levels.
• OFF:
If you do not want to set a volume limit, select
“OFF”.
In this case, the volume can be set to the AVR-
4806CI’s maximum volume (output) level of +18
dB, which is extremely loud.
2 Press the CURSOR D D or H H button to select the
desired setting, then press the CURSOR F F or G G
button to select the parameter.
Setting the Volume Control
• Set the upper limit for the volume, the volume level when
the power is turned on, and the volume level when the mute
mode is set for the different zones.
1 Press the CURSOR D D or H H button to select
“Volume Control” at the “Option Setup”
menu, then press the
ENTER button.
• Display the “Volume Control” screen.
Power On Level:
Set the volume that is set when the power is
turned on for the different zones.
You can adjust the volume level within the range of
–80 to +18 dB in steps of 1.0 dB.
• – – – (Mute)
The volume is always muted when the power is
turned on.
• LAST
The volume set when the AVR-4806CI was last
used is stored in the memory and set when the
power is turned on.
3 Press the ENTER button to enter the setting.
• The “Option Setup” menu reappears.
Mute Level:
Set the volume attenuation level when the mute
mode is set for the different zones.
• FULL
The volume is fully muted.
• –40 dB
The volume is lowered 40 dB from the current
level.
• –20 dB
The volume is lowered 20 dB from the current
level.
Volume Level:
Set whether to fix the output level for the different
zones or make it variable.
• Variable
The level can be adjusted freely using buttons on
the remote control unit.
• –40 dB, 0 dB
The output level is fixed at the set level and the
volume can no longer be adjusted.
• For ZONE2 and ZONE3, the “Volume Limit” and “Power On
Level” can be set when “Variable” is selected for “Volume
Level”.
• When the power amplifier is assigned to either of the
ZONE2 and ZONE3 channels at “Power Amp Assign”,
“–VAR–” (only variable) is displayed and the fixed level
cannot be set.
