Program
ID
Segment
Field Description
UU Usage An 8-bit identifier for the intended usage of the device. The most
significant two bits are determined by the Has Changeable
Interface and Use Field Valued Defined By Functional
Profile check boxes below the Usage box. If you are using a
standard usage value, set the Defined By Functional Profile
check box, click the arrow to select from a list of standard usage
values maintained by L
ON
M
ARK
International. You can update
the list by downloading the latest program ID data from
. If the primary functional profile
implemented by your device specifies custom usage values, clear
the Defined By Functional Profile check box, select
value from 0 – 63 in the box next to the Usage box (the calculator
translates the value to hex for the program ID).
Non-interoperable applications should still use a standard
program ID to describe the device’s usage as closely as possible.
TT Channel
Type
An 8-bit identifier for the channel type supported by the device’s
L
ON
W
ORKS
transceiver. If you are using an FT EVB or if you are
developing a device with an FT Smart Transceiver or FTT-10A
transceiver, select TP/FT-10. If you are using a PL EVB or if you
are developing a device with a PL Smart Transceiver or PLT-22
transceiver, select PL-20C or PL-20N (select PL-20C if you
purchased a PL-20C Evaluation Kit, or PL-20N if you purchased
a PL-20N Evaluation Kit).
Applications linking with the ISI libraries must select the
program ID so that it reports the channel type correctly. Non-
interoperable applications should still use a standard program ID
and advertise the channel type field correctly.
NN
Model Number An 8-bit identifier that you assign to specify the product model for
your device. Assign a unique model number for the specified
manufacturer, device class, usage, and channel type. You can use
the same hardware for multiple model numbers depending on the
program that is loaded into the hardware. The model number
within the program ID does not have to conform to your published
product model number.
N/A Standard
Development
Program ID
This field identifies this device as a development or prototype
device. Select this check box if the device has not been certified by
L
ON
M
ARK
International. Selecting this check box chooses a format
9 standard program ID.
