To build an application image for the example Neuron C applications, you
must select the correct library as shown in Table 2.1. For more
information on the ISI libraries, see the ISI Programmer’s Guide.
Table 2.1 ISI Libraries
Example Application
ISI Library
MGDemo
IsiFull.lib
MGSwitch, MGLight
IsiCompactManual.lib
MGKeyboard
IsiCompactAuto.lib
5. Enter the hardware template for the device in Target Hardware box.
A hardware template defines the memory layout, transceiver type, and
Neuron processor type for the hardware platform to be supported by the
application image. Click the arrow to select from a list of available
hardware templates. The list includes hardware templates for the
evaluation boards.
To build an application image for one of the evaluation boards included
with the Mini EVK, select one of the hardware templates listed in Table
2.2. This choice depends on which Mini EVK model you are using, and
whether you are building an application image for a 3120 EVB or a 3150
EVB.
Table 2.2 Hardware Templates
Mini EVK Model
3120 EVB Hardware
Template
3150 EVB Hardware
Template
Mini EVK PL-20C
PL 3120 EVB,
CENELEC
PL 3150 EVB,
CENELEC
Mini EVK PL-20N
PL 3120 EVB,
Non-CENELEC
PL 3150 EVB,
Non-CENELEC
Mini EVK TP/FT-10
FT 3120 Evaluation
Board
FT 3150 Evaluation
Board
The CENELEC access protocol is a European-standard protocol for
controlling access to a power line used for communication. It is required
for PL-20 devices in most of Europe, but is not required or typically used
outside of Europe. See Chapter 8 of the PL 3120 / PL 3150 Smart
Transceiver Data Book for more information on the CENELEC protocol.
You can download the PL 3120 / PL 3150 Smart Transceiver Data Book
from Echelon’s Web site at
6. Next, enter the application’s program ID. The program ID uniquely
identifies an application, and must be different for every type of device on
