CMG Router - Release 2.7 4-9
Profile Directory:Local Profile
LAN (Local) Profile Setup
Setup < >
Additional setup screens for the Local (LAN) profile. The screen that is accessed
depends on the chosen option. Listed below are the available field options:
Used to configure static network routes that can be reached locally. See Static Networks on page 4-
10, for more information.
Configure static addresses for the local devices. See Static Addresses on page 4-15, for more
information.
Define data filters for this Adit unit. Filtering provides additional security by restricting which
packets will be forwarded to/from the LAN. See Filters on page 4-18, for more information.
Enables the unit to advertise all networks and services to all remote units, or to advertise to no
remotes. See Advertise Network/Server on page 4-25, for more information.
Establish the Adit as a DHCP Server or BOOTP Relay Agent. See DHCP Server/Client/Relay on
page 4-30, for more information.
Adjust the threshold at which excessive LAN collisions trigger an alarm. See LAN Collision
Threshold on page 4-36, for more information.
Add a secondary IP address and subnet to the specified LAN interface. The router will then be capable
of routing between subnets on the LAN interface or between the LAN subnets and any WAN subnet.
A maximum of 8 secondary IP addresses can be added to the LAN interface. See Secondary IP
Address on page 4-42 for more information.
Sets the ethernet PHY mode and speed for the Router.
NOTE: It is highly recommended that this setting be left at auto-negotiation.
Connection of Ethernet devices with incompatible settings can lead to severe
performance degradation and errors on a network.
See Link Speed on page 4-44, for more information.
