Carrier Access CMG Router - Manual (Page 247)

CMG Router - Release 2.7 11-21
Router Configuration
Back-to-Back with Frame Relay
Denver Router in Slot 3
Command Description
set 3 default Set Router to default settings
disconnect a:1 Disconnect all connections to the T1 on the
Controller (slot a)
disconnect 3 Disconnect all connections to the router in slot 1
set clock1 a:1 Set primary master transmit clock source
set a:1:all type data Set the T1-1 of the Controller, Type to Data
connect a:1:all 3:1:1 Connect all of T1-1 to the Router that is in slot 1
rename 3 "LocalAdit" "Denver" Rename the Adit 600 from "LocalAdit" (default)
to "Denver" (LAN)
rename 3 "RemoteAdit" "wan1" Rename WAN #1 from "RemoteAdit" (default) to
"wan1"
set 3:1 ip address 2.2.2.1
255.255.255.0 Set the ethernet IP address, in the conventional IP
address format. (Router LAN)
add 3 "wan1" static ip network
1.1.1.0 255.255.255.0 1 Adds a static IP network (route) to the WAN
interface
set 3:1:1 encapsulation fr Set the encapsulation on trunk 1 to Frame Relay
set 3 lmi disable Disable LMI (Local Management Interface)
set 3 "wan1" trunk 1 Set the WAN interface named "wan1" to be
mapped to trunk 1
set 3 "wan1" dlci 101 Set the DLCI number
reset 3 Reboot the router, to enable all configurations set
