7-4 CMG Router - Release 2.7
Verification Window
Ping Utility
START PING < >
Test for device failure.
The single ping test will send one ping, and display the results of the test.
Test for intermittent communication problems.
A continuous ping will send a ping until the test is manually terminated. Results of the
continuous ping test are constantly updated, based on the result of each ping sent. Press
[E SC ] to terminate the test at any time.
Response Window Fields:
IP Address
Displays the IP Address entered on the setup window.
MAC Address
When a Single Ping is successful, the MAC Address is displayed. When the test has failed,
the MAC Address field does not display, and a timeout result is displayed.
Successful Single Ping Unsuccessful Single Ping
Status Status
IP Dst Address : 100.1.0.26 IP Dst Address : 100.1.0.26
IP Src Address : 100.1.0.10 IP Src Address : 100.1.0.10
MAC Address : 00-00_86_62_72_17 MAC Address :
Response Time : < 1ms Last Result : Destination Unreachable
Last Result : Host Responding
Successful Single Ping Unsuccessful Single Ping
Status Status
IP Dst Address : 100.1.0.26 IP Dst Address : 100.1.0.26
IP Src Address : 100.1.0.10 IP Src Address : 100.1.0.10
MAC Address : 00-00_86_62_72_17 MAC Address :
Response Time : < 1ms Last Result : Destination Unreachable
Last Result : Host Responding Response Count: 19 Timeout Count: 0
Response Count: 19 Timeout Count: 0
