11-12 CMG Router - Release 2.7
Router Configuration
Fax and Modem Setup
8. Select a channel or range of channels to configure.
9. Set the Fax setting, from one of the four Fax options:
- a fax call would be treated as a normal voice call. Default.
- will cause the line to transmit in G.711 mode, with silence
suppression disabled, on detection of Fax tones.
- will use T.38 relay if no more than 5 channels are already using T.38
at the same time. Note: there is a limit of six simultaneous T.38 sessions.
- this line will always be able to use T.38 relay.
10. Set the Modem setting, from one of the two Modem options:
- a modem call would be treated as a normal voice call. Default.
- upon detection of a modem tone, the line will switch to G.711
mode, with echo cancellation and silence suppression disabled.
Card Maximum # of Channels configured for T.38 Reserved
CMG 6 Channels
CMG-02 12 Channels
