CMG Router - Release 2.7
8-11
Statistics
Window
Priority Queue
2. Press [E
NTER
]. The Priority Query window will display.
Priority Queue Fields
Auto-Update
The Auto-Update field is either
Clear All
This field will clear the statistic counts. Options are
Priority Fields
Priority
Traffic Type
Priority 1
CMG originated RTP, RTCP, MGCP, RIP, LMI, and LCP packets
Priority 2
High priority forwarded traffic based on IP TOS match, other type of
CMG originated packets
Priority 3
Default priority forwarded traffic arriving on Serial WAN interfaces
Priority 4
Default priority forwarded traffic arriving on Ethernet interfaces
