1-4 CMG Router - Release 2.7
Introduction
Fields
Fields
Scroll Field
A field enclosed in angle brackets is a scrollable option field. While the field is selected
use the following keystrokes:
[S PACEBAR ] will scroll forward through the options
[E NTER ] will open the option’s window or accept the entered value.
Example: Terminal:
Select Field
A field followed by –> is a selectable field, which causes an action to be performed,
highlight the field and press [E
NTER ] to perform the action, for example, to enter the
Trunk Port Setup screen.
Example: SETUP –>
Some selectable fields, such as Main Menu options, are also a scrollable option field.
For example, –>. Press the [S
PACEBAR ] to select the desired option and then
press [E NTER ] to perform the action.
Edit Field
A field value enclosed in parentheses ( ) may be modified by entering an alphanumeric
character.
Example: SYSTEM NAME: (Adit)
You will note that many editable fields are displayed with a default value. To change
this value, highlight the field and type over the existing entry or press [D
ELETE ] and
then enter new value. Note: these fields are case sensitive. To enter this value press
[E
NTER ].
