CMG Router - Release 2.7 4-7
Profile Directory:Local Profile
LAN (Local) Profile Setup
When set to , the local Adit unit will accept the RIPs and SAPs from the LAN and the
networks and services learned from the WAN will be broadcast to the LAN.
The value will enable the local Adit unit to send to the LAN information regarding the
networks and services that it has learned from remote devices on the WAN. However, the unit
will not accept RIPs and SAPs from the LAN.
When this field value is set to , the local Adit unit will monitor the RIPs and SAPs
on the LAN, learn the available networks and services and then pass this information on to the
appropriate remote units on the WAN. Network information from the WAN, however, will not
be broadcast to the LAN.
The value will not allow the local Adit unit to send or receive information regarding
networks and services on the LAN.
Local
unit
Remote
unit
LAN WAN
send and receive network/service
information to/from LAN
Local
unit
Remote
unit
LAN WAN
network/service
information from remote to LAN
Local
unit
Remote
unit
LAN WAN
network/service information
from the LAN and send to the remotes
