CMG Router - Release 2.7 11-5
Router Configuration
Basic VoIP Setup
Command Description
set 6:1:1 encapsulation ppp Set Router trunk encapsulations to Point-to-Point
Protocol.
set 6:1:1 up Set Router trunk as In-Service
set 6:1 ip address {ip-addr}
{mask} Set Router IP Address and Subnet Mask
set 6:1 up Set Router as In-Service
add 6 "RemoteAdit" static ip
network {ip-addr} {mask}
{next-hop-ip-addr} 1 Set router WAN static ip network. Metric set as 1,
normally indicates a direct network
set 6 "RemoteAdit" trunk 1 Set router WAN trunk to port 1
set 6 "RemoteAdit" up Set router WAN as In-Service
set 6 log last detail Set the router log to add new entries and display the log
in detail
set 6 voip sdpaddress 11.168.1.1 Set the address value to be used for the origin
and connection lines in the SDP. (May be required
depending on how the LAN and WAN are configured.)
reset Reset the CMG card, to apply all configurations
