CMG Router - Release 2.7 8-9
Statistics Window
VoIP Channel View
#
The number column identifies the voice channel number within the CMG. There are 48 possible
CMG voice channels, and, on the status screen these are organized into 3 columns of 16
channels each. Each CMG voice channel to be used for VoIP operations must be connected to
an FXS channel on one of the FXS or T1/E1 cards within the same Adit 600 chassis. See CONN
field below.
STATUS
The STATUS column indicates the combined configuration, restart, and call status for each
CMG voice channel.
SIG
The SIG column indicates the signaling type configured for each CMG voice channel.
CONN
The CONN column indicates which external FXS interface is attached to this numbered CMG
voice channel. If there is no FXS channel attached to a CMG voice channel, no VoIP calls can
be made to/from that CMG channel. In this case the status of the CMG channel will be shown
in the channel status screen as Down, even if the CMG voice channel is configured as Up.
STATUS Meaning
Down Channel is configured as Down or the channel is not connected to an FXS
port on the Adit 600.
NotUsed No SIP user ID has been provisioned for the channel.
Restart Channel is configured as Up, MGCP is up, and the channel has issued an
MGCP restart (RSIP) command to the external call agent. The channel will
stay in this state until the call agent responds with a positive
acknowledgement.
Idle The channel has received a positive response to the last restart command and
there is no call active.
Setup An outgoing call (FXS-to-VoIP) is in progress.
Active An incoming call (VoIP-to-FXS) is alerting the FXS endpoint, or an
incoming/outgoing call is active (answered).
Type Meaning
FXSL FXS - Loop Start.
FXSG FXS - Ground Start.
