Reznor ADFH Option - Installation - Roof Curbs Assembly - Manual (Page 27)

Form I-OPT-C, P/N 132900 R17, Page 27
Size 125 150, 175 200, 225 250, 300 350 400
Option CJ1 - Roof Curb for RPB*
A 60-5/8 60-5/8 60-5/8 60-5/8 60-5/8 60-5/8
B 24-5/16 29-13/16 35-5/16 43-9/16 49-1/16 54-1/2
C** 56-15/16 56-15/16 56-15/16 56-15/16 56-15/16 56-15/16
D** 20-9/16 26-1/16 31-9/16 39-13/16 45-5/16 50-13/16
E 25-7/8 31-3/8 36-7/8 45-1/8 50-5/8 56-1/8
F 62-5/32 62-5/32 62-5/32 62-5/32 62-5/32 62-5/32
Wt 90 lbs 95 lbs 101 lbs 111 lbs 117 lbs 123 lbs
Option CJ2 - Roof Curb for RPB* with Factory-In stalled Downturn
Plenum Option AQ5 or AQ8
A 84-9/16 84-9/16 84-9/16 84-9/16 84-9/16 84-9/16
B 24-5/16 29-13/16 35-5/16 43-9/16 49-1/16 54-1/2
C** 80-13/16 80-13/16 80-13/16 80-13/16 80-13/16 80-13/16
D** 20-9/16 26-1/16 31-9/16 39-13/16 45-5/16 50-13/16
E 25-7/8 31-3/8 36-7/8 45-1/8 50-5/8 56-1/8
F 86-1/16 86-1/16 86-1/16 86-1/16 86-1/16 86-1/16
G 38-5/8 38-5/8 38-5/8 38-5/8 38-5/8 38-5/8
Wt 112 lbs 118 lbs 124 lbs 133 lbs 139 lbs 145 lbs
Size 125 150, 175 200, 225 250, 300 350 400
Option CJ1 - Roof Curb for RPB*
A 1540 1540 1540 1540 1540 1540
B 618 757 897 1106 1246 1384
C** 1446 1446 1446 1446 1446 1446
D** 522 662 802 1011 1151 1291
E 658 797 937 1146 1286 1426
F 1579 1579 1579 1579 1579 1579
Wt 41 kg 43 kg 46 kg 50 kg 53 kg 56 lg
Option CJ2 - Roof Curb for RPB* with Factory-Installed
Downturn Plenum Option AQ5 or AQ8
A 2148 2148 2148 2148 2148 2148
B 618 757 897 1106 1246 1384
C** 2053 2053 2053 2053 2053 2053
D** 522 662 802 1011 1151 1291
E 658 797 937 1146 1286 1426
F 2186 2186 2186 2186 2186 2186
G 981 981 981 981 981 981
Wt 51 kg 54 kg 56 kg 60 kg 63 kg 66 lg
Dimensions (mm ± 6) Dimensions (inches ± 1/4")
Roof Curb Dimensions for Model Series RPB - Refer to FIGURE 9.
* Applies to Models
with prefix “H”
** C and D are
roof opening
dimensions.
Size 400 500/600 700 800 1050 1200
Option CJ1 - Roof Curb for *RPBL
A 82-1/4 108-1/4 108-1/4 108-1/4 134-1/4 134-1/4
B 54-1/2 43-9/16 49-1/16 54-1/2 49-1/16 54-1/2
C** 78-1/2 104-1/2 104-1/2 104-1/2 130-1/2 130-1/2
D** 50-13/16 39-13/16 45-5/16 50-13/16 45-5/16 50-13/16
E 56-1/8 45-1/8 50-5/8 56-1/8 50-5/8 56-1/8
F 83-3/4 109-3/4 109-3/4 109-3/4 135-3/4 135-3/4
Wt 150 lbs 167 lbs 173 lbs 179 lbs 202 lbs 208 lbs
Option CJ2 - Roof Curb for */RPBL with Factory-Installed Downturn Plenum
Option AQ5 or AQ8
A 106-1/4 132-1/4 132-1/4 132-1/4 158-1/4 158-1/4
B 54-1/2 43-9/16 49-1/16 54-1/2 49-1/16 54-1/2
C** 102-1/2 128-1/2 128-1/2 128-1/2 154-1/2 154-1/2
D** 50-13/16 39-13/16 45-5/16 50-13/16 45-5/16 50-13/16
E 56-1/8 45-1/8 50-5/8 56-1/8 50-5/8 56-1/8
F 107-3/4 133-3/4 133-3/4 133-3/4 159-3/4 159-3/4
G 60-5/16 86-5/16 86-5/16 86-5/16 112-5/16 112-5/16
Wt 177 lbs 193 lbs 199 lbs 205 lbs 228 lbs 234 lbs
Option CJ4 - Roof Curb for *RPBL with Field-Installed *** Cooling Coil
Cabinet Option AU2 or AU3
A 150-1/4 165-1/4 170-3/4 176-1/4 196-3/4 202-1/4
B 54-1/2 43-9/16 49-1/16 54-1/2 49-1/16 54-1/2
C** 146-1/2 161-1/2 167 172-1/2 193 198-1/2
D** 50-13/16 39-13/16 45-5/16 50-13/16 45-5/16 50-13/16
E 56-1/8 45-1/8 50-5/8 56-1/8 50-5/8 56-1/8
F 151-1/32 166-1/32 171-17/32 177-1/32 197-17/32 203-1/32
Wt 227 lbs 231 lbs 243 lbs 255 lbs 271 lbs 282 lbs
Option CJ5 - Roof Curb for *RPBL with Field-Installed *** Cooling Coil
Cabinet with Downturn Plenum Cabinet Option AU11, AU12, AU13 or AU14
A 174-1/4 189-1/4 194-3/4 200-1/4 220-3/4 226-1/4
B 54-1/2 43-9/16 49-1/16 54-1/2 49-1/16 54-1/2
C** 170-1/2 185-1/2 191 196-1/2 217 222-1/2
D** 50-13/16 39-13/16 45-5/16 50-13/16 45-5/16 50-13/16
E 56-1/8 45-1/8 50-5/8 56-1/8 50-5/8 56-1/8
F 170-1/32 190-1/32 195-17/32 201-1/32 221-17/32 227-1/32
G 127-17/32 142-17/32 148-1/32 153-17/32 174-1/32 179-17/32
Wt 253 lbs 257 lbs 269 lbs 280 lbs 296 lbs 308 lbs
Size 400 500/600 700 800 1050 1200
Option CJ1 - Roof Curb for *RPBL - mm
A 2089 2750 2750 2750 3410 3410
B 1384 1106 1246 1384 1246 1384
C** 1994 2654 2654 2654 3315 3315
D** 1291 1011 1151 1291 1151 1291
E 1426 1146 1286 1426 1286 1426
F 2127 2788 2788 2788 3448 3448
Wt 68 kg 76 kg 78 kg 81 kg 92 kg 94 kg
Option CJ2 - Roof Curb for *RPBL with Factory-Installed
Downturn Plenum Option AQ5 or AQ8
A 2699 3359 3359 3359 4020 4020
B 1384 1106 1246 1384 1246 1384
C** 2604 3264 3264 3264 3924 3924
D** 1291 1011 1151 1291 1151 1291
E 1426 1146 1286 1426 1286 1426
F 2637 3397 3397 3397 4058 4058
G 1532 2192 2192 2192 2853 2853
Wt 80 kg 88 kg 90 kg 93 kg 103 kg 106 kg
Option CJ4 - Roof Curb for *RPBL with Field-Installed ***
Cooling Coil Cabinet Option AU2 or AU3 - mm
A 3816 4197 4337 4477 4997 5137
B 1384 1106 1246 1384 1246 1384
C** 3721 4102 4242 4382 4902 5042
D** 1291 1011 1151 1291 1151 1291
E 1426 1146 1286 1426 1286 1426
F 3836 4217 4357 4497 5017 5157
Wt 103 kg 105 kg 110 kg 116 kg 123 kg 128 kg
Option CJ5 - Roof Curb for *RPBL with Field-Installed
*** Cooling Coil Cabinet with Downturn Plenum Cabinet
Option AU11, AU12, AU13 or AU14 - mm
A 4426 4807 4947 5086 5607 5747
B 1384 1106 1246 1384 1246 1384
C** 4331 4712 4851 4991 5512 5652
D** 1291 1011 1151 1291 1151 1291
E 1426 1146 1286 1426 1286 1426
F 4319 4827 4966 5106 5627 5767
G 3239 3620 3760 3900 4420 4560
Wt 115 kg 117 kg 122 kg 127 kg 134 kg 140 kg
Dimensions (mm ± 6) Dimensions (inches ± 1/4")
Roof Curb Dimensions for Model Series RPBL - Refer to FIGURE 9.
* Applies to Models with
prefix “H”.
** C and D are roof
opening dimensions.
*** Field installed means
that the cooling coil
cabinet with or without
the downturn is factory
assembled and
shipped separately.
The roof curb is sized
to accommodate the
complete length of the
system.
The shipped-separate
cooling coil cabinet with
or without a downturn
must be lifted to the
roof separately from the
packaged system, set
on the roof curb, and
attached to the furnace
section. NOTE: If the
coil is field supplied,
install the coil in the
cabinet before lifting.
Packaged System Models Blower
Cabinet
H
RPB RPBL inches mm
125 17-3/8 441
150, 175 22-7/8 581
200, 225 28-3/8 721
250, 300 500, 600 36-5/8 930
350 700, 1050 42-1/8 1070
400 400, 800, 1200 RBL 47-5/8 1210
Roof Curb Dimensions for Blower Cabinet Model RBL - Refer to FIGURE 9.
Dimensions (inches ± 1/4") Dimensions (mm ± 6)
Model RBL
Option CJ1 -
for Standard
Cabinet
Option CJ2 - with
Downturn Plenum
Option AQ5 or AQ8
A 59-1/16" 82-1/16"
B 53-9/16" 53-9/16"
C** 55-5/16" 78-5/16"
D** 49-13/16" 49-13/16"
E 55-15/16" 55-15/16"
F 60-7/16" 83-1/2"
G N/A 36-5/16"
Wt 120 lbs 145 lbs
Model RBL
Option CJ1 -
or Standard
Cabinet
Option CJ2 - with
Downturn Plenum
Option AQ5 or AQ8
A 1500 mm 2084 mm
B 1360 mm 1360 mm
C** 1405 mm 1989 mm
D** 1265 mm 1265 mm
E 1421 mm 1421 mm
F 1535 mm 2121 mm
G N/A 922 mm
Wt 54 kg 66 kg
Duct Width - Dimension H, FIGURE 9.
