Reznor ADFH Option - Installation - Roof Curbs Assembly - Manual (Page 20)

Form I-OPT-C, Page 20
Model RDH, REH, or RXH (without hot
water module) Configuration *
Option
Code
Model and Size
Pkg
P/N
Curb End
(Front & Rear)
Assy
Curb Side
Assy RDH REH RXH**
Model RDH or REH Basic Unit ONLY
(blower and heat section) AND
Model RXH Basic Unit ONLY
(blower & plenum only; for RXH with hot
water heat module, see CJ8H-P)
CJ8A
75/100 10A/20A/30A 000A 215047 (2) 215037 (2) 215041
125/150 15B/30B/60B 000B 215048 (2) 215038 (2) 215041
175/200/225 N/A 000C 215049 (2) 215037 (2) 215042
250/300 30D/60D/90D/120D 000D 215050 (2) 215039 (2) 215042
350/400A 40E/80E/120E 000E 215051 (2) 215040 (2) 215042
Basic unit PLUS one optional module
-- either Downturn Plenum, OR Mixing
Box, OR Cooling Cabinet Module
without Reheat (AU5 or AU6)
CJ8B
75/100 10A/20A/30A 000A 215052 (2) 215037 (2) 215043
125/150 15B/30B/60B 000B 215053 (2) 215038 (2) 215043
175/200/225 N/A 000C 215054 (2) 215037 (2) 215044
250/300 30D/60D/90D/120D 000D 215055 (2) 215039 (2) 215044
350/400A 40E/80E/120E 000E 215056 (2) 215040 (2) 215044
Basic unit PLUS a Cooling Cabinet
Module with Reheat (AU7 or AU8)
CJ8E
75/100 10A/20A/30A 000A 223750 (2) 215037 (2) 234940
125/150 15B/30B/60B 000B 223751 (2) 215038 (2) 234940
175/200/225 N/A 000C 223752 (2) 215037 (2) 234941
250/300 30D/60D/90D/120D 000D 223753 (2) 215039 (2) 234941
350/400A 40E/80E/120E 000E 223754 (2) 215040 (2) 234941
Basic unit PLUS two optional modules
-- either Downturn Plenum AND Mixing
Box or Cooling Cabinet Module without
Reheat (AU5 or AU6), OR Mixing Box
AND Cooling Cabinet Module without
Reheat (AU5 or AU6)
CJ8C
75/100 10A/20A/30A 000A 215057 (2) 215037 (2) 215045
125/150 15B/30B/60B 000B 215058 (2) 215038 (2) 215045
175/200/225 N/A 000C 215059 (2) 215037 (2) 215046
250/300 30D/60D/90D/120D 000D 215060 (2) 215039 (2) 215046
350/400A 40E/80E/120E 000E 215061 (2) 215040 (2) 215046
Basic unit PLUS two optional modules
-- either Downturn Plenum & Cooling
Cabinet Module with Reheat (AU7 or
AU8), OR Mixing Box & Cooling Cabinet
Module with Reheat (AU7 or AU8)
CJ8F
75/100 10A/20A/30A 000A 223755 (2) 215037 (2) 234942
125/150 15B/30B/60B 000B 223756 (2) 215038 (2) 234942
175/200/225 N/A 000C 223757 (2) 215037 (2) 234943
250/300 30D/60D/90D/120D 000D 223758 (2) 215039 (2) 234943
350/400A 40E/80E/120E 000E 223759 (2) 215040 (2) 243943
Basic unit PLUS three optional modules
-- Downturn Plenum, AND Mixing Box,
AND Cooling Cabinet Module without
Reheat (AU5 or AU6)
CJ8D
75/100 10A/20A/30A 000A 214421 (2) 215037 (2) 216227
125/150 15B/30B/60B 000B 214422 (2) 215038 (2) 216227
175/200/225 N/A 000C 214423 (2) 215037 (2) 216228
250/300 30D/60D/90D/120D 000D 214424 (2) 215039 (2) 216228
350/400A 40E/80E/120E 000E 214425 (2) 215040 (2) 216228
Basic unit PLUS three optional modules
-- Downturn Plenum, AND Mixing Box,
AND Cooling Cabinet Module with
Reheat (AU7 or AU8)
CJ8G
75/100 10A/20A/30A 000A 223760 (2) 215037 (2) 234944
125/150 15B/30B/60B 000B 223761 (2) 215038 (2) 234944
175/200/225 N/A 000C 223762 (2) 215037 (2) 234945
250/300 30D/60D/90D/120D 000D 223763 (2) 215039 (2) 234945
350/400A 40E/80E/120E 000E 223764 (2) 215040 (2) 234945
*Model RDH/REH/RHH/RXH
configuration may also include an
evaporative cooling module. The
evaporative cooling module does
not affect the length of the roof
curb.
** Applies to Model RXH without a
hot water heat module
Options CJ8A - CJ8G
(right) apply to Models
RDH, REH, and RXH
without a hot water heat
module
Options CJ8H - CJ8P
(below) apply to Model
RXH with a hot water
heat module (Option
HW2)
Options CJ8Q - CJ8W
(top of page 21) apply
to Model RHH
Model RXH with Option HW2 (hot water heat module) Configuration * Option RXH WITH Option HW2 Pkg P/N Curb End (Front & Rear) Assy Curb Side Assy
Model RXH with Optional Hot Water Heat Module (HW2) and horizontal
discharge
CJ8H
000A 260877 (2) 261546 (2) 261522
000B 260878 (2) 261547 (2) 261522
000C 260879 (2) 261546 (2) 261523
000D 260880 (2) 261548 (2) 261523
000E 260881 (2) 261549 (2) 261523
Model RXH with Optional Hot Water Heat Module (HW2) PLUS 1 either
Downturn Discharge Plenum (AQ5 or AQ8); OR Mixing Box (MXB1)
with horizontal discharge; OR Cooling Coil Cabinet without Reheat
(AU5 or AU6) with horizontal discharge
CJ8J
000A 260882 (2) 261546 (2) 261524
000B 260883 (2) 261547 (2) 261524
000C 260884 (2) 261546 (2) 261525
000D 260885 (2) 261548 (2) 261525
000E 260886 (2) 261549 (2) 261525
Model RXH with Optional Hot Water Heat Module (HW2) PLUS 2 -
Down Discharge (AQ 5 or AQ8) AND Mixing Box OR Cooling Coil
Cabinet without Reheat (AU 5 or 6); OR Mixing Box AND Cooling Coil
Cabinet without Reheat (AU 5 or 6) with horizontal discharge
CJ8K
000A 260887 (2) 261546 (2) 261526
000B 260888 (2) 261547 (2) 261526
000C 260889 (2) 261546 (2) 261527
000D 260890 (2) 261548 (2) 261527
000E 260891 (2) 261549 (2) 261527
Model RXH with Optional Hot Water Heat Module (HW2) PLUS 3 -
Down Discharge Plenum (AQ5 or AQ8) AND Mixing Box (MXB1) AND
Cooling Coil Cabinet without Reheat (AU5 or AU6)
CJ8L
000A 260892 (2) 261546 (2) 261528
000B 260893 (2) 261547 (2) 261528
000C 260894 (2) 261546 (2) 261529
000D 260895 (2) 261548 (2) 261529
000E 260896 (2) 261549 (2) 261529
Model RXH with Optional Hot Water Heat Module (HW2) PLUS 1 -
Cooling Coil Cabinet with Reheat (AU7) with horizontal discharge
CJ8M
000A 260897 (2) 261546 (2) 261530
000B 260898 (2) 261547 (2) 261530
000C 260899 (2) 261546 (2) 261531
000D 260900 (2) 261548 (2) 261531
000E 260901 (2) 261549 (2) 261531
Model RXH with Optional Hot Water Heat Module (HW2) PLUS 2 -
Cooling Coil Cabinet with Reheat (AU7) AND Down Discharge Plenum
(AQ5 or AQ8) OR Mixing Box (MXB1) with horizontal discharge
CJ8N
000A 260902 (2) 261546 (2) 261532
000B 260903 (2) 261547 (2) 261532
000C 260904 (2) 261546 (2) 261458
000D 260905 (2) 261548 (2) 261458
000E 260906 (2) 261549 (2) 261458
Model RXH with Optional Hot Water Heat Module (HW2) PLUS 3 -
Cooling Coil Cabinet with Reheat (AU7) AND Down Discharge Plenum
(AQ5 or AQ8) AND Mixing Box (MXB1)
CJ8P
000A 260907 (2) 261546 (2) 261459
000B 260908 (2) 261547 (2) 261459
000C 260909 (2) 261546 (2) 261545
000D 260910 (2) 261548 (2) 261545
000E 260911 (2) 261549 (2) 261545
4.0 Roof Curbs for
PreevA ® Models RDH,
REH, RHH, and RXH
(cont'd)
COMPONENTS of
Roof Curb Packages
for PreevA ® Models
(cont'd)
Hardware and Tape
Shipped with ALL
PreevA ® Roof Curbs
(12) P/N 16247, Cap Screw 5/16"-18x3/4" long; (12) P/N
1035, Hex Nut 5/16"-18; (4) P/N 16243, Lag Screw 5/16"x1"
long; (16) P/N 1333, Lockwasher 5/16"; and (1) P/N 66302,
1/4'x1-1/4"x50' Foam Sealant Tape
