Reznor ADFH Option - Installation - Roof Curbs Assembly - Manual (Page 23)

Form I-OPT-C, P/N 132900 R17, Page 23
Locations of
Bottom Duct
Connections -
FIGURE 7C
NOTE: Duct openings should be 1" (25mm) larger than the duct size for installation clearance.
RDH Size REH Size
RXH**
Size
Dimensions (inches ±1/8) Dimensions (mm ±3)
F H K (w/mixing box & downturn) F H K (w/mixing box & downturn)
(with mixing box
and/or down
discharge)
no
cooling
coil
module
with a cooling coil
module
(w/mixing
box and/
or down
discharge)
no
cooling
coil
module
with a cooling coil
module
no
reheat
with
reheat
no
reheat
with
reheat
75/100 10A/20A/30A 000A 22-7/8 1-9/16 81-5/8 109-3/8 134-3/8 581 40 2073 2778 3413
125/150 15B/30B/60B 000B 26-1/2 4-3/4 81-5/8 109-3/8 134-3/8 673 121 2073 2778 3413
175/200/225 N/A 000C 22-7/8 1-9/16 97-3/8 125-1/8 150-1/8 581 40 2473 3178 3813
250/300 30D/60D/90D/120D 000D 34-3/4 3-3/4 97-3/8 125-1/8 150-1/8 883 96 2473 3178 3813
350/400A 40E/80E/120E 000E 45-13/16 2-1/4 97-3/8 125-1/8 150-1/8 1164 57 2473 3178 3813
Dimensions and Weights of Optional Roof Curbs for Model RXH with Optional Hot Water Heat
Module (Option HW2) - See FIGURE 7C
Configuration * - Model RXH
with HW2
Option
Code
RXH with Optional Hot
Water Heat Module
Inches (±1/8) mm (±3) Weight
A B C D A B C D lbs kg
Model RXH with Optional Hot Water Heat
Module (HW2) and horizontal discharge
CJ8H
000A 68-5/8 29-13/16 64-7/8 26-1/16 1743 757 1648 662 115 52
000B 68-5/8 39-13/16 64-7/8 36-1/16 1743 1011 1648 916 127 58
000C 84-3/8 29-13/16 80-5/8 26-1/16 2143 757 2048 662 134 61
000D 84-3/8 46-1/16 80-5/8 42-5/16 2143 1170 2048 1075 153 69
000E 84-3/8 54-1/16 80-5/8 50-5/16 2143 1373 2048 1278 153 69
Model RXH with Optional Hot Water Heat
Module (HW2) PLUS 1 either Downturn
Discharge Plenum (AQ5 or AQ8); OR Mixing Box
(MXB1) with horizontal discharge; OR Cooling
Coil Cabinet without Reheat (AU5 or AU6) with
horizontal discharge
CJ8J
000A 96-3/8 29-13/16 92-5/8 26-1/16 2448 757 2353 662 148 67
000B 96-3/8 39-13/16 92-5/8 36-1/16 2448 1011 2353 916 160 73
000C 112-1/8 29-13/16 108-3/8 26-1/16 2848 757 2753 662 167 76
000D 112-1/8 46-1/16 108-3/8 42-5/16 2848 1170 2753 1075 167 76
000E 112-1/8 54-1/16 108-3/8 50-5/16 2848 1373 2753 1278 167 76
Model RXH with Optional Hot Water Heat
Module (HW2) PLUS 2 - Down Discharge (AQ
5 or AQ8) AND Mixing Box OR Cooling Coil
Cabinet without Reheat (AU 5 or 6); OR Mixing
Box AND Cooling Coil Cabinet without Reheat
(AU 5 or 6) with horizontal discharge
CJ8K
000A 124-1/8 29-13/16 120-3/8 26-1/16 3153 757 3058 662 189 86
000B 124-1/8 39-13/16 120-3/8 36-1/16 3153 1011 3058 916 201 91
000C 139-7/8 29-13/16 136-1/8 26-1/16 3553 757 3458 662 208 94
000D 139-7/8 46-1/16 136-1/8 42-5/16 3553 1170 3458 1075 227 103
000E 139-7/8 54-1/16 136-1/8 50-5/16 3553 1373 3458 1278 237 108
Model RXH with Optional Hot Water Heat Module
(HW2) PLUS 3 - Down Discharge Plenum (AQ5
or AQ8) AND Mixing Box (MXB1) AND Cooling
Coil Cabinet without Reheat (AU5 or AU6)
CJ8L
000A 151-3/4 29-13/16 148 26-1/16 3854 757 3759 662 185 84
000B 151-3/4 39-13/16 148 36-1/16 3854 1011 3759 916 197 89
000C 167-3/8 29-13/16 163-5/8 26-1/16 4251 757 4156 662 204 93
000D 167-3/8 46-1/16 163-5/8 42-5/16 4251 1170 4156 1075 224 102
000E 167-3/8 54-1/16 163-5/8 50-5/16 4251 1373 4156 1278 234 106
Model RXH with Optional Hot Water Heat
Module (HW2) PLUS 1 -
Cooling Coil Cabinet with Reheat (AU7) with
horizontal discharge
CJ8M
000A 121-1/4 29-13/16 117-1/2 26-1/16 3080 757 2985 662 222 101
000B 121-1/4 39-13/16 117-1/2 36-1/16 3080 1011 2985 916 234 106
000C 136-7/8 29-13/16 133-1/8 26-1/16 3477 757 3381 662 241 109
000D 136-7/8 46-1/16 133-1/8 42-5/16 3477 1170 3381 1075 261 118
000E 136-7/8 54-1/16 133-1/8 50-5/16 3477 1373 3381 1278 271 123
Model RXH with Optional Hot Water Heat
Module (HW2) PLUS 2 -
Cooling Coil Cabinet with Reheat (AU7) AND
Down Discharge Plenum (AQ5 or AQ8) OR
Mixing Box (MXB1) with horizontal discharge
CJ8N
000A 148-7/8 29-13/16 145-1/8 26-1/16 3781 757 3686 662 219 99
000B 148-7/8 39-13/16 145-1/8 36-1/16 3781 1011 3686 916 231 105
000C 164-5/8 29-13/16 160-7/8 26-1/16 4181 757 4086 662 238 108
000D 164-5/8 46-1/16 160-7/8 42-5/16 4181 1170 4086 1075 258 117
000E 164-5/8 54-1/16 160-7/8 50-5/16 4181 1373 4086 1278 267 121
Model RXH with Optional Hot Water Heat
Module (HW2) PLUS 3 -
Cooling Coil Cabinet with Reheat (AU7) AND
Down Discharge Plenum (AQ5 or AQ8) AND
Mixing Box (MXB1)
CJ8P
000A 176-3/4 29-13/16 173 26-1/16 4489 757 4394 662 252 114
000B 176-3/4 39-13/16 173 36-1/16 4489 1011 4394 916 265 120
000C 192-3/8 29-13/16 188-5/8 26-1/16 4886 757 4791 662 271 123
000D 192-3/8 46-1/16 188-5/8 42-5/16 4886 1170 4791 1075 291 132
000E 192-3/8 54-1/16 188-5/8 50-5/16 4886 1373 4791 1278 301 137
Model RXH
(with hot
water heat
module)
Dimensions (inches ±1/8) Dimensions (mm ±3)
F H K (with mixing box & downturn) F H K (with mixing box & downturn)
(with mixing box
and/or down
discharge)
no cooling
coil
module
with a cooling coil
module
(with mixing box
and/or down
discharge)
no cooling
coil
module
with a cooling coil
module
no reheat with reheat no reheat with reheat
000A 22-7/8 1-9/16 98-7/16 126-3/16 151-3/16 581 40 2500 3205 3840
000B 26-1/2 4-3/4 98-7/16 126-3/16 151-3/16 673 121 2500 3205 3840
000C 22-7/8 1-9/16 114-3/16 141-15/16 166-15/16 581 40 2900 3605 4240
000D 34-3/4 3-3/4 114-3/16 141-15/16 166-15/16 883 96 2900 3605 4240
000E 45-13/16 2-1/4 114-3/16 141-15/16 166-15/16 1164 57 2900 3605 4240
Dimensions for
Locations of Bottom
Duct Connections as
shown in FIGURE 7C
for Model RXH with a
hot water heat module
NOTE: Duct openings should be 1” (25mm) larger than the duct size for installation clearance.
*Configuration may also include an evaporative cooling module. The evaporative cooling module does not affect the length of the
roof curb.
