Form I-OPT-C, P/N 132900 R17, Page 1
Form I-OPT-C (Version Q)
Obsoletes Form I-OPT-C (Version P)
®
Applies to:
Roof Curbs for Reznor
®
Model Series ADF, ADFH; RCB, RCC,
RDB, RDC, RDCB, RDCC, RDDB, RDDC, RECB, RECC,
REDB, REDC; RDF; RDH, REH, RHH, RXH; RPB; RPBL;
RPDBL; Blower Cabinet RBL; YDHA, YDMA, and YDSA
Curb Description
By Reznor
®
Model
Installation of Option CJ Roof Curbs
Optional curbs are available to fit all sizes and all horizontal configurations of the
Reznor
®
outdoor equipment listed above.
Consult the
APPENDIX in the specific Installation Manual of that product for system
installation information and attaching ductwork.
MAPS
®
III Models RCB, RDB, RDCB, RDDB, RECB, REDB & MAPS
®
IV Models
RCC, RDC, RDCC, RDDC, RECC, REDC Cabinet Sizes A, B, and C - Optional curbs
are for either down or horizontal supply air. All curbs are shipped in factory-assembled
sections for field installation. Curb sides are constructed of 16-gauge coated steel and
wooden nailers. All hardware necessary to assemble the curb is provided; installation
hardware must be field supplied.
Downflow curbs, Options CJ31 and CJ34, are 14" (356mm) high. Down discharge roof
curbs include dividers that allow for inserting ductwork down from the top.
The roof curbs for horizontal supply air discharge for MAPS
®
"A" and "B" cabinets,
Options CJ50 and CJ54, are 32" high (813mm), and curbs for "C" cabinets, Options
CJ49 and CJ53, are 36" (914mm) high. All of the horizontal supply curbs include inte-
gral supply and return air ducts with adjacent duct flanges.
Model Series ADF(H); MAPS
®
III RCB, RDB, RDCB, RDDB, RECB, REDB Cabi-
net Size D; RDF; PreevA
®
RDH, REH, RHH, RXH; RPB, RPBL, RPDBL; ZQYRA;
Blower Cabinet Model RBL and YDHA, YDMA & YDSA (Cabinet Sizes 1 & 2) -
Optional curbs for downflow supply air are shipped in factory-assembled sections for
field installation. Curbs are 16" (406mm) high and are constructed of 16-gauge coated
steel and 2x6 wooden nailers. From this list of models, only curb packages for Models
ZQYRA; RCB, RDB, RDCB, RDDB, RECB, REDB; and RDF include field-installed
dividers creating integral ductwork. All hardware necessary to assemble the curb is
provided; installation hardware must be field supplied.
GENERAL
GENERAL ........................................................................................ 1
RDCC, RDDC, RECC, REDC - Cabinet Sizes A, B, and C ...... 2
1.1 Curb for Vertical (Down) Airflow (Option CJ31) - applies
to units without energy recovery ..........................................2
III&IV A, B, & C Cabinet with Vertical
(Down) Airflow WITH an Optional Energy Recovery Module,
Option ER1A, ER1B, ER1C (Roof Curb Option CJ34) .......5
1.3 Roof Curbs for Horizontal Airflow (Options CJ49 & CJ50) ...7
1.4 Roof Curbs for Horizontal Airflow (Options CJ54 & CJ53)
III&IV Cabinets A, B, and C WITH an Energy
Recovery Module ...............................................................10
RDDB, RECB, REDB Cabinet Size D ..................................... 14
3.0 Roof Curbs for Z Series Model ZQYRA ................................ 17
Models RDH, REH, RHH, & RXH ... 19
5.0 Roof Curbs for Model Series ADF, ADFH; RPB, RPBL,
RPDBL; and Blower Cabinet Model RBL - Options
CJ1, CJ2, CJ3, CJ4, CJ5, CJ6, CJ7 ....................................... 24
5.1 Curb Installation Instructions for all Models in Section 5.0 ..24
5.2 Roof Curb Packages for Model Series RPB and RPBL
& Blower Cabinet Model RBL ............................................
5.3 Roof Curb Packages for Model Series RPDBL
5.4 Roof Curb Packages for Model Series ADF and ADFH
6.0 Roof Curbs for Model Series RDF ......................................... 30
7.0 Roof Curbs for Models YDHA, YDMA, YDSA ....................... 32
7.1 Downflow Roof Curbs ........................................................32
7.2 Roof Curbs for Horizontal Airflow - Options CJ48 &
CJ55 ..................................................................................35
...................................................................................... 39
Installation
Requirements and
Recommendations
that Apply to ALL
Reznor
®
Roof Curbs
• Before installation, verify (1) that the curb ordered is the appropriate one for the
unit and (2) that the curb supplied is the correct size.
• Position the curb depending on roof structure and so that the air inlet is not facing
into the prevailing wind. Depending on the weight and the roof structure, tread
material may be required under the rails. Curb and equipment must be level.
• If installing more than one system, it is recommended to minimize structural span
deflection to discourage sound transmission.
• Mounting hardware and flashing must be field supplied.
• Assembly and installation of the curb are the responsibility of the installer.
