71M6533- DB Demo Board User’s Manual
Page: 63 of 75 REV 3
4.2 71M6533-DB DEMO BOARD BILL OF MATERIAL
Table 4-1: 71M6533-DB Demo Board: Bill of Material
Item Q Reference Part
PCB
Footprint
Digi-Key/Mouser Part
Number Part Number Manufacturer
1 1 C1 2200uF radial P5143-ND ECA-1CM222 Panasonic
2 3 C2,C4,C45 10uF RC1812 478-1672-1-ND TAJB106K010R AVX
3 8 C5,C17-C20,C22,C28,C29 0.1uF RC0603 445-1314-1-ND C1608X7R1H104K TDK
4 1 C6 0.47uF B1918-ND 2222 383 30474 Vishay
5 29 C8-C13,C15,C23,C33-C44 1000pF RC0603 445-1298-1-ND C1608X7R2A102K TDK
C47-C51, C56-C59
6 3 C21,C32,C54 NC RC0603
7 1 C24 33pF RC0603 445-1275-1-ND C1608C0G1H330J TDK
8 1 C25 7pF RC0603 490-3564-1-ND GQM1885C1H7R0CB01D Murata
9 13 C26,C27,C31,C60-C68 22pF RC0603 445-1273-1-ND C1608C0G1H220J TDK
10 1 C46 0.03uF axial 75-125LS30-R 125LS30-R Vishay
11 1 C52 1uF RC0603 PCC2224CT-ND ECJ-1VB1C105K Panasonic
12 2 C53,C55 100pF RC0603 445-1281-1-ND C1608C0G1H101J TDK
13 1 D1 UCLAMP3301D SOD-323 -- UCLAMP3301D.TCT SEMTECH
14 1 D3 6.8V ZENER D041 1N4736ADICT-ND 1N4736A-T DIODES
15 1 D4 Switching Diode D035 1N4148DICT-ND 1N4148-T DIODES
16 2 D5,D6 LED radial 404-1104-ND H-3000L Stanley
17 1 D8 NC SOD-323
18 1 J1 DC jack (2.5mm) RAPC712 502-RAPC712X RAPC712X Switchcraft
19 1 J2 HEADER 8X2 8X2PIN S2011E-36-ND PZC36DAAN Sullins
20 4 J3,J5,J7,J16 HEADER 2 2X1PIN S1011E-36-ND PZC36SAAN Sullins
21 4 J4,J6,J8,J9 Spade Terminal A24747CT-ND 62395-1 AMP
22 1 J10 DUAL ROW 12X2 PIN MALE 12X2PIN 929665-09-12-ND 3M
23 1 J11 DUAL ROW 12X2 PIN FEMALE 12X2PIN S7115-ND PPPC122LFBN-RC Sullins
24 1 J12 HEADER 5 5X1PIN S1011E-36-ND PZC36SAAN Sullins
25 1 J13 HEADER 4 4X1PIN S1011E-36-ND PZC36SAAN Sullins
26 1 J14 10X2 CONNECTOR, 0.05" 571-5-104068-1 5-104068-1 AMP
27 1 J17 HEADER 6 6X1PIN S1011E-36-ND PZC36SAAN Sullins
28 1 J18 HEADER 5X2 5X2PIN S2011E-36-ND PZC36DAAN Sullins
29 6 JP1,JP13,JP14,JP15,JP17,JP18 HEADER 2 2X1PIN S1011E-36-ND PZC36SAAN Sullins
30 5 JP6,JP7,JP8,JP16,JP19,JP20 HEADER 3 3X1PIN S1011E-36-ND PZC36SAAN Sullins
31 1 JP12 HEADER 9 9X1PIN S1011E-36-ND PZC36SAAN Sullins
32 17 L1-L9,L11-L18 Ferrite bead, 600 Ohm RC0805 445-1556-1-ND MMZ2012S601A TDK
33 3 RV1,RV2,RV3 VARISTOR radial 594-2381-594-55116 238159455116 Vishay
34 1 R2 8.06K, 1% RC0805 311-8.06KCRCT-ND RC0805FR-078060KL Yageo
35 1 R4 25.5K, 1% RC0805 311-25.5KCRCT-ND RC08052FR-072552L Yageo
36 4 R6,R65,R73,R141 100, 2W axial 100W-2-ND RSF200JB-100R Yageo
37 1 R7 130, 1% RC1206 311-130FRCT-ND RC1206FR-071300L Yageo
38 1 R9 68, 1% RC1206 311-68.0FRCT-ND RC1206FR-0768R0L Yageo
39 11 R10,R11,R12,R90,R92,R93, 62 RC0805 P62ACT-ND ERJ-6GEYJ620V Panasonic
R95,R96,R97,R98,R99
40 7 R14,R32,R34,R52,R53,R72, 750, 1% RC0805 P750CCT-ND ERJ-6ENF7500V Panasonic
R135
41 33 R15-R21,R26-R29,R38-R44, 220K, 1% RC0805 311-220KCRCT-ND RC0805FR-07220KL Yageo
R46-R49,R58-R64,R66-R69
42 8 R24,R25,R36,R37,R56,R57 3.4, 1% RC1206 311-3.40FRCT-ND RC1206FR-073R40L Yageo
R136,R137
43 3 R30,R50,R70 120K, 1% RC0805 311-120KCRCT-ND RC0805FR-071203L Yageo
44 3 R31,R51,R71 4.70K, 1% RC0805 311-4.70KCRCT-ND RC0805FR-074701L Yageo
45 9 R74,R76,R80,R103,R104,R105, 10K RC0805 P10KACT-ND ERJ-6GEYJ103V Panasonic
R106,R107
46 2 R75,R94 0 RC0805 P0.0ACT-ND ERJ-6GEY0R00V Panasonic
47 1 R77 NC RC0805
48 4 R78,R91,R108,R111 1K RC0805 P1.0KACT-ND ERJ-6GEYJ102V Panasonic
49 2 R79, R110 100 RC0805 P100ACT-ND ERJ-6GEYJ101J Panasonic
50 1 R83 16.9K, 1% RC0805 P16.9KCCT-ND ERJ-6ENF1692V Panasonic
51 1 R86 20.0K, 1% RC0805 P20.0KCCT-ND ERJ-6ENF2002V Panasonic
52 3 R100,R101,R102 100K RC0805 P100KACT-ND ERJ-6GEYJ104V Panasonic
53 4 R131,R132,R133,R134 0 RC1206 P0.0ECT-ND ERJ-8GEY0R00V Panasonic
54 1 R139 1.5 RC1206 P1.5ECT-ND ERJ-8GEYJ1R5V Panasonic
55 1 SW2,SW3 SWITCH P8051SCT-ND EVQ-PJX05M Panasonic
56 10 TP1-TP8,TP20,TP21 TP 2X1PIN S1011E-36-ND PZC36SAAN Sullins
57 1 TP10 TP 3X1PIN S1011E-36-ND PZC36SAAN Sullins
58 4 TP13-TP16 Test Point 5011K-ND 5011 Keystone 1)
60 3 U1,U2,U3,U7 BAV99DW SOT363 BAV99DW-FDICT-ND BAV99DW-7-F DIODES
61 1 U4 SER EEPROM SO8 AT24C256BN-10SU-1.8-ND AT24C256BN-10SU-1.8 ATMEL
62 1 U5 71M6533 100TQFP -- 71M6533-IGT TERIDIAN
63 1 at U5 100TQFP Socket 100TQFP -- IC149-100-154B51 Yamaichi
64 1 U6 REGULATOR, 1% SO8 296-1288-1-ND TL431AIDR Texas Instruments
65 1 Y1 32.768kHz XC1195CT-ND ECS-.327-12.5-17X-TR ECS
66 1 U8 LCD, 3.3V 153-1110-ND VIM-828-DP5.7-6-RC-S-LV VARITRONIX 2)
