71M6533- DB Demo Board User’s Manual
Page: 59 of 75 ` REV 3
4 APPENDIX
This appendix includes the following documentation, tables and drawings:
71M6533-DB Demo Board Description

71M6533-DB Demo Board Electrical Schematic

71M6533-DB Demo Board Bill of Materials

71M6533-DB Demo Board PCB layers (copper, silk screen, top and bottom side)

71M6533-DB Demo Board Electrical Schematic
71M6533/71M6533H IC Description

71M6533/71M6533H Pin Description

71M6533/71M6533H Pin-out
4
