EVCO S.p.A. c-pro 3 | Hardware manual ver. 3.2 | Codice 114CP3E324
page 76 of 116
Diagnostic Key Par parameter available in read only modality
result of the copy of the parameters from the
controller to the programming key EVKEY10
and vice versa
ok = operation successful
completed
err = operazione failed
Debug
[ Algo ]
Main time parameter available in read only modality
main cycle time of the application software
(in milliseconds)
Int. time parameter available in read only modality
interrupt cycle time of the application
software (in milliseconds)
Debug
[ CAN bus ]
rx parameter available in read only modality number of packages in transmission
tx parameter available in read only modality number of packages in reception
Debug
[ CAN bus ]
err parameter available in read only modality number of packages in error
ovf parameter available in read only modality number of packages in overflow
Debug
24VPS parameter available in read only modality misura della tensione di alimentazione
5VP parameter available in read only modality
reading the power supply voltage of the
ratiometric transducers
Debug
24VP parameter available in read only modality
reading the power supply voltage of the
0-20 mA / 4-20 mA / 0-10 V transducers
24VE parameter available in read only modality
reading the power supply voltage of the user
interface
Debug
Stack parameter available in read only modality minimum free stack
Buf parameter available in read only modality number of free buffers
Notes:
(1) the submenu is visible on condition that the application software expects the first RS-485 port is configured to support the
Modbus communication protocol
(2) the submenu is visible on condition that the application software expects the second RS-485 port is configured to support the
Modbus communication protocol
(3) the parameter is meaningful on condition that the second RS-485 port is configured to support the Modbus master
communication protocol
(4) the parameter is visible only in c-pro 3 NODE mega.
