APPENDIX H
H-3
APPENDIX H
(cont.)
__________________________
Table H-1. BMS II Standard Input Register Address Mapping-Cont.
Modbus Data
Address (Hex) Menu Item Units and Range Comments
0x0011
Thru
0x0018
Not Applicable Used for 8 BMS Legacy
(PWM) Boilers Only
0x0019 Boiler 1 Status
(Net Boiler 1)
119 = Not On-Line
120 = On-Line But Not Fired
1–40 = Fired & Sequence
121 = On-Line But Disabled
122 = On-Line But Faulted BMS II has only Network
Boilers so Net Boiler 1 =
Boiler 1, etc.
0x001A Boiler 2 Status
(Net Boiler 2) Same As Above
0x001B Boiler 3 Status
(Net Boiler 3) Same As Above
0x001C Boiler 4 Status
(Net Boiler 4) Same As Above
0x001D Boiler 5 Status
(Net Boiler 5) Same As Above
0x001E Boiler 6 Status
(Net Boiler 6) Same As Above
0x001F Boiler 7 Status
(Net Boiler 7) Same As Above
0x0020 Boiler 8 Status
(Net Boiler 8) Same As Above
0x0021 Boiler 9 Status
(Net Boiler 9) Same As Above
0x0022 Boiler 10 Status
(Net Boiler 10)
Same As Above
0x0023 Boiler 11 Status
(Net Boiler 11)
Same As Above
0x0024 Boiler 12 Status
(Net Boiler 12) Same As Above
0x0025 Boiler 13 Status
(Net Boiler 13)
Same As Above
0x0026 Boiler 14 Status
(Net Boiler 14)
Same As Above
